Mostrando 1 - 20 de 114

A comparative study of performance and regulated emissions in a medium-duty diesel engine fueled with sugarcane diesel-farnesane and sugarcane biodiesel-LS9
(ELSEVIER, 2019-06-01) Soto, Felipe; Marques, Gian; Torres-Jiménez, Eloísa; Vieira, Bráulio; Lacerda, André; Armas, Octavio; Guerrero-Villar, Francisca
Two sugarcane biofuels and mineral diesel fuel are tested under full load conditions, under the same values of performance and under the European Transient Cycle on an engine test bench, without any modifications to the ECU. The target is to compare engine performance and emissions. At full load, engine performance varies due to the variation in LHV. Under the same values of performance, the sugarcane biodiesel-LS9 provides the lowest THC emissions. The higher CN and exhaust gas recirculation of the sugarcane biodiesel-LS9 and the higher H/C ratio of the sugarcane diesel-farnesane compared to the diesel S50 provide a NOx reduction. Neither the increment in bsfc nor the increment of %EGR for the sugarcane biodiesel-LS9 deteriorate the combustion, so its CO emissions are lower. The sugarcane biodiesel-LS9 leads to the lowest NOx and PM specific emissions under transient operation, followed by the sugarcane diesel-farnesane. The THC and CO specific emissions are higher for the biofuels in comparison to the diesel S50. The main reason for these results is the impact of the properties of the biofuels on the ECU response However, both biofuels produce less harmful emissions at idle conditions, which supports their usage to reduce exhaust emissions in urban areas.
A higher order thermoelastic analysis of fatigue crack growth can assess crack tip shielding
(Wiley, 2023-06-30) Camacho-Reyes, Alonso; Vasco-Olmo, José M.; James, M. Neil; Díaz, Francisco A.
The present work uses a more accurate thermoelastic formulation than the classical equation, based on the inclusion of a higher order term, to analyze crack tip thermoelastic data. It is shown that this thermoelastic analysis (TSA) model can be fitted to the Christopher–James–Patterson crack tip field model and hence provides information on crack tip shielding. To validate the results of this analysis, stress intensity factors (SIFs) were compared with results obtained from digital image correlation (also fitted to the CJP model). A comparison was also made between these CJP-derived SIF values and those obtained using a purely elastic Irwin–Westergaard approach. A high level of agreement was observed between DIC and TSA results in assessing ΔKCJP that is the net result of the driving and the shielding forces on the crack tip. The ability to assess shielding using TSA is a significant step forward in its potential use in a more accurate characterization of crack tip fields.
A material model to reproduce mixed-mode fracture in concrete
(Wiley, 2018-08) Suárez Guerra, Fernando; Gálvez, Jaime C.; Cendón , David A.
This paper presents a material model to reproduce crack propagation in cement-based material specimens under mixed-mode loading. Its numerical formulation is based on the cohesive crack model, proposed by Hillerborg, and extended for the mixed-mode case. This model is inspired by former works by Gálvez et al but implemented for its use in a finite element code at a material level, that is to say, at an integration point level. Among its main features, the model is able to predict the crack orientation and can reproduce the fracture behaviour under mixed-mode fracture loading. In addition, several experimental results found in the literature are properly reproduced by the model.
A meshfree approach for analyzing strain fields near crack tips from Digital Image Correlation displacement data
(Wiley, 2024-03-24) Gómez-Gonzales, Giancarlo Luis; Camacho-Reyes, Alonso; Ortiz-González, Julián Andrés; Diaz-Garrido, Francisco Alberto
The element-free Galerkin (EFG) meshfree method is employed in this research to compute strain fields based on discrete displacement data obtained from digital image correlation (DIC). To validate the method's accuracy, both simulated images with highly heterogeneous deformations and real tests conducted on notched specimens with known solutions are initially employed. The study then investigates the strain field near the crack tip in an AISI 1020 steel specimen through a multiscale experiment. From the macroscale experiment, the strain data are used to determine the crack-tip plastic zone size, and the solution is compared with predictions from linear-elastic fracture mechanics. The stress intensity factor is also determined. Furthermore, the high strain gradient ahead of the crack tip is determined from the microscale experiment and compared against commercial DIC software. Experimental results confirm the effectiveness of the proposed formulation in crack tip analysis.
A single-stage megaflood at the termination of the Messinian Salinity Crisis: Geophysical and modelling evidence from the eastern Mediterranean Basin
(Elsevier, 2020-09-10) Spatola, Daniele; del-Moral-Erencia, José David; Micallef, Aaron; Camerlenghi, Angelo; García-Castellanos, Daniel; Gupta, Sanjeev; Bohórquez, Patricio; Gutscher, Marc-André; Bertoni, Claudia
The Messinian salinity crisis was an extraordinary event that resulted in the deposition of kilometre-thick evaporite sequences in the Mediterranean Sea after the latter became disconnected from the world's oceans. The return to fully and stable marine conditions at the end of the crisis is still subject to debate. Three main hypotheses, based on geophysical and borehole data, onshore outcrops and climate simulations, have been put forward. These include a single-stage catastrophic flood, a two-step reflooding scenario, and an overspill of Paratethyan water followed by Atlantic inflow. In this study, two research questions are addressed: (i) Which event marked the termination of the Messinian salinity crisis? (ii) What was the sea level in the eastern Mediterranean Sea during this event? Geophysical data from the western Ionian Basin are integrated with numerical simulations to infer that the termination of the crisis consisted of a single-stage megaflood following a sea level drawdown of 1900 m. This megaflood deposited an extensive sedimentary body with a chaotic to transparent seismic signature at the base of the Malta Escarpment. Fine, well-sorted sediments are predicted to have been deposited within the thicker sections of the flood deposit, whereas a more variable distribution of coarser sediments is expected elsewhere. The north-western Ionian Basin hosts evidence of episodic post-Messinian salinity crisis slope instability events in the last ~1.8 Ma. The largest of these emplaced a >200 km3 deposit and is associated with failure of the head of Noto Canyon (offshore SE Sicily). Apart from unravelling the final phase of the Messinian salinity crisis and the ensuing stratigraphic evolution of the western Ionian Basin, our results are also relevant to better understand megafloods, which are some of the most catastrophic geological processes on Earth and Mars.
A smeared crack formulation for simulating fracture of fibre-reinforced concrete by means of a trilinear softening diagram
(Elsevier, 2023-08) Suárez Guerra, Fernando
This study presents a smeared crack model for reproducing the fracture behaviour of FRC that is based on an embedded crack formulation used lately with this material. In both cases, a trilinear softening diagram allows reproducing the post-peak behaviour correctly. The model proposed here differs from the one on which it is inspired, since it is a smeared crack model based on the crack band concept where the material damage is isotropic and controlled by a damage factor ranging from 0 to 1, while the original model is an embedded crack model that allows fracture in three directions per element. This new formulation overcomes some limitations of the embedded crack model, that could only be used with triangular elements with an only integration point, since it can be used with triangular and quadrilateral elements with any number of integration points. Unlike previous models, developed for commercial codes, this model is developed in OOFEM, a free finite element code developed at the Czech Technical University in Prague (Czech Republic) and Chalmers University of Technology (Sweden), thus providing the general public with an advanced tool that allows reproducing fracture in structural elements made with fibre-reinforced concrete elements. This work shows that the proposed formulation provides similar results to those obtained with the model on which it is inspired under different situations: mode I fracture, size effect analysis and, finally, modes I and II mixed fracture.
A technical overview of metallic parts in hybrid additive manufacturing industry
(Elsevier, 2022-05) Erdi Korkmaz, Mehmet; Waqar, Saad; García-Collado, A.; Kumar Gupta, Munish; Krolczyk, Grzegorz
Additive manufacturing technologies have emerged as the promising alternatives of conventional manufacturing techniques. Conventional manufacturing techniques involves cutting and removal of material by mechanical procedures to achieve final product. Whereas, discrete chunks of material in any form are combined point by point and layer by layer for the fabrication of final product in additive manufacturing processes. Numerous advantages and inefficiencies of these manufacturing techniques are reflected in factors such as the design, fabrication, material properties and working condition etc. Therefore, development of a production technology by combining the benefits of both conventional and additive techniques is significantly important. “Hybrid Manufacturing” jointly apply additive and conventional production methods to attain final products. Hence, this short overview covers the operation aspects of both additive and subtractive manufacturing of metallic materials.
Advances in polymers based Multi-Material Additive-Manufacturing Techniques: State-of-art review on properties and applications
(Elsevier, 2022-02) García-Collado, Alberto; Blanco, José Miguel; Gupta, Munish; Dorado-Vicente, Rubén
Recently, the demand and studies related with Multi-Material Additive Manufacturing (MMAM) is continuously increasing. To uncover the essential knowledge hidden in the current mess of research works, this study, based on a simple review methodology, helps to identify and discuss the current knowledge about: limitations of software and hardware, the interface bonding strength of dissimilar materials, polymer reinforcement with continuous fiber, polymer-based multi-materials, and future and challenges. The review method starts with a list of topics to check: MMAM of polymers, the bonding strength between materials, knowledge gaps, and new development lines in polymer applications. Then, it continues with the search procedure on electronic databases and the inclusion and exclusion criteria definition. Finally, to help the discussion and assessment, the information is collected in tables.
Alternative Calibration of Cup Anemometers: A Way to Reduce the Uncertainty of Wind Power Density Estimation
(MDPI, 2019-04-30) Guerrero-Villar, Francisca; Dorado-Vicente, Rubén; Medina-Sánchez, Gustavo; Torres-Jiménez, Eloísa
This study presents a procedure to reduce the uncertainty of wind power density estimations, which is useful to improve the energy production predictions of wind farms. Power density is usually determined from the wind speed measured by a cup anemometer and the air density value (conventional procedure). An alternative procedure based on wind speed and dynamic pressure estimations provided by a cup anemometer is proposed. The dynamic pressure is obtained by means of a calibration curve that relates the anemometer rotation frequency and the dynamic pressure measured by a Pitot tube. The quadratic regression, used to define the calibration curve, and its uncertainty are both detailed. A comparison between the alternative procedure and the conventional one points out the advantage of the proposed alternative since results show a high reduction of the indirect measurement uncertainty of wind power density.
An alternative approach for improving DIC by using out-of-plane displacement information
(Elsevier, 2020-05-01) Siegmann, Philip; Felipe-Sesé, Luis; Díaz, Francisco
A new approach to perform 2D Digital Image Correlation (DIC) on objects that are subjected to large out-of-plane displacements is presented. It employs out-of-plane information to distort the speckle images of the reference and the deformed surface, increasing their similarity and therefore their sub-set cross-correlation peaks. The new approach is implemented using the combined Fringe Projection and 2D-DIC technique on two experiments: The buckling of an initial flat plate, and the rotation of the reference surface towards the camera from 0° to 60°. In both cases large speckle distortions are produced due to two issues, the lens magnification and the surface tilting. The first speckle distortion is applied to the deformed image to perform the lens magnification correction, and the second speckle distortion is applied to the reference image. The obtained distorted speckle images become very similar, allowing to successfully compute corresponding pixels between both images in a simple way (i.e. without nonlinear minimization processes). For this propose, an analytical iterative equation is derived to determine pixel displacements due to out-of-plane surface tilting. The resulting displacements are compared with those obtained by the conventional procedure, applying 2D-DIC (using open source Ncorr software) on the non-distorted speckle images and then making the lens magnification correction. The novel procedure proposed makes it possible to successfully find the corresponding pixels at the reference surface for out-of-plane rotations of 55° and 60° for which Ncorr failed. 3D-DIC (using commercial VIC software) is also employed to validate the results.
An alternative procedure to measure railroad track irregularities. Application to a scaled track
(ELSEVIER, 2019) Fernández-Aceituno, Javier; Chamorro, Rosario; Muñoz-Moreno, Sergio; Escalona, José Luis
In this paper an alternative procedure to accurately measure static railroad track irregularities is proposed and applied to a scaled railroad track. The purpose of this work is the determination of highlyprecise measured data in short track segments that needs to be used as input in the validation of railroad computational models that are used for on-board railroad track measurement systems. The procedure consists of the use of a topographic total station combined with a postprocessing of the measured data that reduces misalignment errors and provide the analytical ideal geometry of the track together with its irregular geometry characterized in terms of the magnitudes of track gauge, vertical profile, alignment and cross level. Experimental results are compared to standard magnitudes of full scale tracks showing that real track geometry can differ from PSD-based predicted one. This supports the application of the proposed procedure for an accurate geometric determination of short track segments.
An automatic procedure for calibrating the fracture parameters of fibre-reinforced concrete
(Elsevier, 2025-02-21) Suárez-Guerra, Fernando; Donaire-Ávila, Jesús; Fernández-Aceituno, Javier
In this work a calibration procedure to obtain the material parameters that characterize the fracture behaviour of fibre-reinforced concrete (FRC) is presented. This procedure uses a recently proposed trilinear softening diagram implemented in a smeared crack model of the free finite element code OOFEM that allows reproducing the fracture behaviour of FRC and takes advantage of the optimization package of SciPy, with both pieces of software being open-source and of free access for anyone interested in this field. This work presents the calibration procedure, which uses the Nelder-Mead algorithm to adjust the numerical result with the experimental diagram and discusses some key aspects, such as the number of reference points used in the calibration process or the weighting factors used with them, including the possibility of making some reference points more relevant than others in the calibration process. The influence of the mesh size and the element type used in the FEM model is also analysed. To evaluate the quality of the numerical approximation, a deviation factor is defined, which provides an scalar value that becomes lower as the numerical adjustment is closer to the experimental diagram in the reference points. The proposed procedure allows calibrating six parameters automatically with a meaningful time reduction and good accuracy. Using a higher number of reference points may lead to a better adjustment, although this study suggests that a good selection of the reference points is more effective than using a high number of reference points or using weighting factors to make some points more relevant than others. This procedure is finally validated by applying it with experimental results obtained with other types of FRC materials (different fibres and different fibre proportions) and specimen geometries.
Analysis of the two-point wheel-rail contact scenario using the knife-edge-equivalent contact constraint method
(ELSEVIER, 2020) Fernández-Aceituno, Javier; Urda, Pedro; Briales, Eduardo; Escalona, José Luis
This paper presents a rigid contact approach to analyse the two-point wheel-rail contact scenario using the simplified constraint-based contact method called Knife-edge Equivalent Contact method (KEC-method). The proposed approach makes use of the computationally efficient online solution of the KEC constraints, where a single-point rail is in contact with an equivalent wheel profile, and provides an exact relation between the location of the contact points in the equivalent and real profiles. In this context, the two-point contact scenario can be easily dealt by linearly softening the KEC-constraints in the vicinity of the two-point contact, that gives a continuous and unique contact point solution between each wheel-rail pair and avoids finite contact point jumps between tread and flange. This allows an efficient kinematic solution of the two-point contact scenario. However, to properly ac- count for a dynamic equivalence of the two-point contact scenario in the computation of the tangential contact forces, the reaction force acting on the wheel when the contact point lies on the tread-flange transition, is transformed into two contact forces acting on the tread and flange respectively maintaining the resultant equilibrium of forces at the wheel.
Analysis of two experimental setups to study mode II fracture on fibre-reinforced gypsum notched specimens
(CSIC, 2023-09) Suárez-Guerra, Fernando; Fernández-Aceituno, Javier; Donaire-Ávila, Jesús
The main aim of this work is to study two relevant experimental setups designed for studying shear fracture and see if any of them allows studying the evolution of fracture under Mode II conditions, not only inducing a shear stress state at the onset of fracture. Two tests have been selected, a standardised test described by a Japanese standard, here referred to as the JSCE test, and the push-off test. These tests have been carried out on fibre-reinforced gypsum specimens with increasing proportions of polypropylene fibres and monitored by means of digital image correlation (DIC). The results show that fracture under Mode II conditions is relatively easy to induce with both tests, but once fracture begins, it is extremely difficult to induce a fracture process under Mode II. In general, Mode II has an important role at the onset on fracture, but Mode I predominates afterwards.
Application of the Finite Element Method to the Incremental Forming of Polymer Sheets: The Thermomechanical Coupled Model and Experimental Validations
(MDPI, 2020-07) GARCIA-COLLADO, ALBERTO; Medina-Sanchez, Gustavo; Kumar Gupta, Munish; Dorado-Vicente, R.
Single Point Incremental Forming (SPIF) is an innovative die-less low-cost forming method. Until now, there have not been viable numerical solutions regarding computational time and accuracy for the incremental forming of polymers. Unlike other numerical approaches, this novel work describes a coupled thermomechanical finite element model that simulates the SPIF of polymer sheets, where a simple elastoplastic constitutive equation rules the mechanical behavior. The resulting simulation attains a commitment between time and accuracy in the prediction of forming forces, generated and transmitted heat, as well as final part dimensions. An experimental test with default process parameters was used to determine an adequate numerical configuration (element type, mesh resolution, and material model). Finally, compared to a set of experimental tests with different thermoplastics, the proposed model, which does not consider complex rheological material models, shows a good agreement with an approximation error of less than 11% in the vertical forming force prediction.
Applied computer vision for composite material manufacturing by optimizing the impregnation velocity: An experimental approach
(Elsevier, 2021-11-30) Almazán-Lázaro, Juan Antonio; López-Alba, Elías; Díaz-Garrido, Francisco Alberto
The application of the cutting edge industrial solutions in composite manufacturing are optimizing the processes, quality control and resources usage. Computer vision is currently used in many quality control stages, although its potential advantages have not been applied in the process control. In this paper, computer vision is used to control the impregnation velocity in VARI (Vacuum Assisted Resin Infusion) process. As it is known, there is a relationship between the impregnation velocity and the final mechanical properties in LCM (Liquid Composite Manufacturing) processes. Constant and optimum flow front velocity mean optimum mechanical properties, although the nature of the process makes it difficult to keep these conditions. Then, a methodology has been proposed to identify and use the optimum velocity during the manufacturing process. Firstly, the flow front recognition algorithm was calibrated to be used in different reinforcement and fluid systems. Then, tensile and impact specimens have been manufactured and tested at different controlled and uncontrolled velocities. As a result, the tensile modulus has been increased up to 12.6%, as the tensile strength has increased up to 8.7%. Similarly, the maximum reaction force during the impact test has been increased up to 6.5%, as the damaged area has been reduced by 8.8%. For stitched laminates, force results increase up to 3.2%, as the damaged area has been reduced up to 31% when the optimum velocity is used. The experimental results have demonstrated the advantage of using mechanisms to control the impregnation process to achieve improved mechanical properties of composite materials.
Artificial neural networks applied to the measurement of lateral wheel-rail contact force: A comparison with a harmonic cancellation method
(ELSEVIER, 2020) Urda, Pedro; Fernández-Aceituno, Javier; Muñoz-Moreno, Sergio; Escalona, José Luis
This paper presents a method for the experimental measurement of the lateral wheel-rail contact force based on Artificial Neural Networks (ANN). It is intended to demonstrate how an Artificial Intelligence (AI) method proves to be a valid alternative to other approaches based on sophisticated mathematical models when it is applied to the wheel-rail contact force measurement problem. This manuscript addresses the problem from a computational and experimental approach. The artificial intelligence algorithm has been experimentally tested in a real scenario using a 1:10 instrumented scaled railway vehicle equipped with a dynamometric wheelset running on a 5-inch-wide track. The obtained results show that the ANN approach is an easy and computationally efficient method to measure the applied lateral force on the instrumented wheel that requires the use of fewer sensors.
Assessment of Tailings Ponds by a Combination of Electrical (ERT and IP) and Hydrochemical Techniques (Linares, Southern Spain)
(SPRINGER LINK, 2020-09-01) Rey, Javier; Martínez, Julián; Hidalgo, M. Carmen; Mendoza, Rosendo; Sandoval, Senen
Accumulated mine waste in certain locations in the abandoned mining district of Linares-La Carolina (southern Spain) contain high levels of metals. Therefore, in recent years, many of these tailings ponds have been restored and sealed. This study assessed the efficacy of two geophysical techniques, electrical resistivity tomography (ERT) and induced polarisation (IP), combined with hydrochemical studies, as tools to image the effectiveness of the encapsulation. In the bedrock, ERT profiles distinguished a surficial layer of moderate-low resistivity values (below 80 Ω m), associated with alluvial sands or altered granite, and a deeper zone of high resistivity (up to 1000 Ω m) related to unaltered granite basement. Lateral changes in resistivity were identified inside the upper layer and downstream of the tailings pond. The IP profiles detected local anomalies in the chargeability values (up to 8 mV/V), unusual in granitic rocks. The locations with high chargeability also had low resistivity, which typically indicates the percolation of mining leachates in the underlying altered granites. Integration of geological and geochemical information confirmed this interpretation. This work verified that the combined use of ERT and IP methods were effective for monitoring ancient tailings ponds and for assessing tailings encapsulation.
Bubble pressure requirements to control the bubbling process in forced co-axial air-water jets
(Elsevier, 2020-12-01) Ruiz-Rus, Javier; Bolaños-Jiménez, Rocío; Sevilla-Santiago, Alejandro; Martínez-Bazán, Carlos
We analyse the controlled generation of bubbles of a given size at a determined bubbling rate in a co-flowing water stream forcing the gas flow. The temporal evolution of the bubble size, R(t), the air flow rate, Qa(t), and the pressure evolution inside the bubble, pb(t), during the bubbling process are reported. To that aim, the temporal evolution of the bubble shape and the pressure inside the air feeding chamber, pc(t), where a harmonic perturbation is induced using a loudspeaker, are obtained from high-speed images synchronized with pressure measurements. A model is developed to describe the unsteady motion of the gas stream along the injection needle, coupled with the Rayleigh-Plesset equation for the growing bubble, allowing us to obtain pb(t). Thus, the minimum pressure amplitudes required inside the forming bubble to control their size and bubbling frequency are provided as a function of the gas flow rate, the liquid velocity, uw, and the forcing frequency, ff. Two different behaviors have been observed, depending on the liquid-to-gas velocity ratio, Λ. For small enough values of Λ, the critical pressure amplitude is given by p_s ∼ ρ_a c u_a St_f3, associated to a rapid pressure increase taking place during an interval of time of the order of the acoustic time. However, for larger values of Λ, ps ∼ ρ u_w^2 St_f^3 Λ^{−1/5} We^{−1/4}. Here ρ and ρa are the liquid and gas densities respectively, c the speed of sound in air and St_f = f_f r_o/u_w and We = ρ u_w^2 r_o/σ the Strouhal and Weber numbers, where r_o denotes the outer radius of the injector.
Build Time Estimation for Fused Filament Fabrication via Average Printing Speed
(MDPI, 2019-12-01) Medina-Sánchez, Gustavo; Dorado-Vicente, Rubén; Torres-Jiménez, Eloisa; López-García, Rafael
Build time is a key issue in additive manufacturing, but even nowadays, its accurate estimation is challenging. This work proposes a build time estimation method for fused filament fabrication (FFF) based on an average printing speed model. It captures the printer kinematics by fitting printing speed measurements for diﬀerent interpolation segment lengths and changes of direction along the printing path. Unlike analytical approaches, printer users do not need to know the printer kinematics parameters such as maximum speed and acceleration or how the printer movement is programmed to obtain an accurate estimation. To build the proposed model, few measurements are needed. Two approaches are proposed: a fitting procedure via linear and power approximations, and a Coons patch. The procedure was applied to three desktop FFF printers, and diﬀerent infill patterns and part shapes were tested. The proposed method provides a robust and accurate estimation with a maximum relative error below 8.5%.
