Examinando por Autor "De la Morena de la Fuente, Eduardo"
Mostrando 1 - 5 de 5
- Resultados por página
- Opciones de ordenación
Ítem Agustin de Betancourt’s Wind Machine for Draining Marshy Ground: Approach to Its Geometric Modeling with Autodesk Inventor Professional(Multidisciplinary Digital Publishing Institute, 2016-12-26) Rojas Sola, José Ignacio; De la Morena de la Fuente, EduardoThe present study shows the process followed in making the three-dimensional model and geometric documentation of a historical invention of the renowned Spanish engineer Agustin de Betancourt y Molina, which forms part of his rich legacy. Specifically, this was a wind machine for draining marshy ground, designed in 1789. The present research relies on the computer-aided design (CAD) techniques using Autodesk Inventor Professional software, based on the scant information provided by the only two drawings of the machine, making it necessary to propose a number of dimensional and geometric hypotheses as well as a series of movement restrictions (degrees of freedom), to arrive at a consistent design. The results offer a functional design for this historic invention.Ítem Geometric Modeling of the Machine for Cutting Cane and Other Aquatic Plants in Navigable Waterways by Agustín de Betancourt y Molina(Multidisciplinary Digital Publishing Institute, 2018-02-11) Rojas Sola, José Ignacio; De la Morena de la Fuente, EduardoThis article presents the steps followed to obtain a three-dimensional model of one of the most recognized historical inventions of Agustín de Betancourt y Molina from the scant documentation found about it. Specifically, this was a machine for cutting cane and other aquatic plants in navigable waterways, presented in London in 1795. The study is based on computer-aided design (CAD) techniques using Autodesk Inventor Professional, from the information provided by the only two sheets that exist from the machine, one with specifications in English and the other in French, both very similar. In order to obtain a functional result on which to carry out further studies, it has been necessary to make some geometrical hypotheses on the models, aimed to find the correct dimension of each element. In addition, it has also been necessary to define the relationship of each element with those that set up its environment, defining movement restrictions, so that the final model, behaves as real as possible.Ítem The Conical Stones Olive Oil Mill: Analysis through Computer-Aided Engineering(Multidisciplinary Digital Publishing Institute, 2020-07-01) Rojas Sola, José Ignacio; De la Morena de la Fuente, EduardoThis article analyzes an olive oil mill formed of four conical stones used in the milling of the olive. To this end, a study of computer-aided engineering (CAE) was carried out using the parametric software Autodesk Inventor Professional, consisting of a static analysis using the finite-element method (FEM) of the three-dimensional (3D) model of the mill under real operating conditions. The results obtained revealed that the conical stones mill was a very robust machine. When studying the assembly in the most unfavorable situation (blockage of one of its millstones), we observed that the element with the highest von Mises stress was the bearing nut, reaching a value of 263.9 MPa, which was far from the elastic limit of cast iron (758 MPa). On the other hand, the machine hardly presented any equivalent deformations or displacements that could jeopardize the operation as a whole. The maximum displacement obtained was 2.494 mm in the inertia flywheel, and the equivalent deformations did not reach 0.1% of the part dimension. Similarly, the element with the lowest safety coefficient (2.87) was the same bearing nut with the highest von Mises stress, although the next element with the second lowest safety coefficient had a value of 8.69, which showed that the set was clearly oversized. These results demonstrate the convenience of redesigning the set in order to resize some of its elements, and that they could have lower safety coefficients of between 2 and 4. After an initial analysis, the resizable elements would fundamentally be those related to the movement transmission system and the frame structure.Ítem The Hay Inclined Plane in Coalbrookdale (Shropshire, England): Analysis through Computer-Aided Engineering(Multidisciplinary Digital Publishing Institute, 2019-08-16) Rojas Sola, José Ignacio; De la Morena de la Fuente, EduardoThis article analyzes the ‘Hay inclined plane’ designed by the English engineer and entrepreneur William Reynolds and put into operation in 1792 to facilitate the transport of vessels between channels at different levels using an inclined plane. To this end, a study of computer-aided engineering (CAE) was carried out using the parametric software Autodesk Inventor Professional, consisting of a static analysis using the finite-element method (FEM) of the 3D model of the invention under real operating conditions. The results obtained after subjecting the mechanism to the two most unfavorable situations (blockage situation of the inertia flywheel and emergency braking situation) indicate that, with the exception of the braking bar, the rest of the assembly is perfectly designed and dimensioned. In particular, for the blockage situation, the point with the greatest stress is at the junction between the inertia flywheel and the axle to which it is attached, the maximum value of von Mises stress being at that point (186.9 MPa) lower than the elastic limit of the cast iron. Also, at this point the deformation is very low (0.13% of its length), as well as the maximum displacement that takes place in the inertia flywheel itself (22.98 mm), and the lowest safety factor has a value of 3.51 (located on the wooden shaft support), which indicates that the mechanism is clearly oversized. On the other hand, the emergency braking situation, which is technically impossible with a manual operation, indicates that the braking bar supports a maximum von Mises stress of 1025 MPa, above the elastic limit of the material, so it would break. However, other than that element, the rest of the elements have lower stresses, with a maximum value of 390.7 MPa, and with safety factors higher than 1.7, which indicates that the mechanism was well dimensioned.Ítem The Tower Press for Obtaining Olive Oil: Analysis through Computer-Aided Engineering(Multidisciplinary Digital Publishing Institute, 2020-11-19) Rojas Sola, José Ignacio; De la Morena de la Fuente, Eduardo; Hermoso Orzáez, Manuel Jesús; Hernández Díaz, DavidThis article analyzes a large tower press used to press crushed olives to obtain olive oil. To this end, a study of computer-aided engineering (CAE) was carried out using the parametric software Autodesk Inventor Professional, consisting of a static analysis using the finite-element method (FEM) of the 3D model of the press under real operating conditions. The tower press has been analyzed in two limit positions: in the rest position, supported on two pillars, and the pressing position, supported on the set of filter discs (basket load) called ‘cargo de capachos’ that contained the previously ground olives. In the first position, static analysis revealed that the maximum von Mises stress was 22.7 MPa, located on the axle of the roller, but this is far from the elastic limit. Moreover, the lowest safety coefficient is 11.16, produced in the contact between the tower and the right pillar and well above the optimal range between 2 and 4. On the other hand, it hardly presents equivalent displacements or deformations that would endanger the operation of the set. The greatest displacement would be in the wooden guide (0.123 mm) and a deformation of 0.027% with respect to its length. These values confirm that, in this position, the tower press was clearly oversized. However, the results obtained regarding the second position are not entirely conclusive. Although the values of the displacements and the equivalent deformations are low, with results similar to those obtained in the first position, with a maximum displacement of 0.1315 mm located in the horizontal beam of the support structure and a maximum equivalent deformation of value 0.385%, located in the contact between the screw and the nut, the same does not happen with the von Mises stress. The software did not obtain a convergent result due to the frustoconical geometry of the bolt that joins the screw and nut, adopting a maximum value of 508.3 MPa. For this point, the safety coefficient is 1.49, which reveals a sizing problem with the proposed solution of resizing the screw thread, giving it more robustness. The rest of the elements work with a safety coefficient above 4.33 so they are also clearly oversized, according to current criteria.
